Veterinary Cattle Horse Digital X ray Machine for Sale

Veterinary RV-80B Stationary digital X-ray imaging system for diagnosis of large animals (cattle, horses, etc.).

Inquiry Now Download as PDF

Product Detail

Applications

Fixed X-ray diagnostic machine for large animals,DR diagnostic equipment for cattle

Performance

80kw high power high frequency high voltage generator.
Reasonable design, simple and generous appearance.
Compartment structure is more suitable for shooting large animals.
Utilizing professional animal medical DR image software, not only reduce the radiation dose, but also ensure the image is clear and stable.
Camera bracket: motorized lifting, intelligent tracking; simple operation, one-key trigger.

High Voltage Generator

Two exposure modes kV-mAs/kV-mA-ms

Flat Panel Detector

17in×17in large imaging area
High performance cesium iodide process with low radiation dose

X-Ray Tube Assembly

-Double focuses: small focal point 1.0mm/ large focus2.0mm. Totally can achieve the balance between the best resolution radio of images and loading power.

-High heat capacity: the heat capacity of tube is 140Khu which can achieve the stability and requirements of continuous exposurean and operation.

-Peak power: small focal point 20kw, large focus 40kw. Can grealy promote the photography conditions to fit animal's variety of body size and the range of body positions. Also fulfill the requirements of loading the special photography.
