The Dawei L3 portable laptop animal reptile ultrasound machine is a high-performance, Windows 10-based notebook-style color Doppler system engineered for the versatile needs of modern small animal clinics and veterinary practices. By combining Spatial Compound Imaging with multi-frequency transducer technology , it provides the precision required for everything from canine abdominal scans to feline cardiac assessments and equine musculoskeletal imaging.
Detailed Veterinary Probe Specifications
The system supports a variety of probes with wide-band frequency conversion to accommodate different species and sizes:
| Probe Type | Frequency Range | Tuning Stages | Primary Veterinary Applications |
| Convex Array (Standard) |
2.0MHz-5.5MHz
|
8-stage conversion |
Abdominal & OB/GYN scans for large dogs and livestock |
| Linear Array (Optional) |
6.0MHz -12.0MHz |
6-stage conversion |
MSK (Tendon), vascular, and superficial exams for small pets. |
| Intracavity/Micro-Convex |
4.5MHz-9.0MHz
|
7-stage conversion |
Specialized feline abdomen and small animal urology. |
-
Multi-Species Diagnostic Versatility: Specialized software packages support diverse veterinary applications, including small animal internal medicine (abdomen, urology), reproductive health (OB/GYN), and specialty diagnostics (pediatrics and vascular).
-
Precision Imaging Architecture:
-
Spatial Compound Imaging: Enhances boundary detection for organ scanning and edge definition.
-
Tissue Harmonic Imaging (THI): Reduces artifacts and improves contrast resolution, critical for larger canine patients.
-
Trapezoidal Imaging: Expands the field of view on linear probes, ideal for examining equine tendons or superficial feline masses.
-
-
Advanced Hemodynamic Analysis:
-
Color Doppler & Directional Power Doppler: High-sensitivity visualization of blood flow in small animal organs.
-
Auto-Spectrum Envelope: Real-time analysis of PS, ED, PI, RI, and S/D provides immediate data on vascular resistance and heart rate (HR).
-
-
Streamlined Veterinary Workflow:
-
One-Key Smart Optimization: Instantly balances gain and contrast for rapid scanning of active or moving animal patients.
-
Integrated Patient Management: Features a professional archive system to record and search by pet owner name or ID.
- Portable Reliability: Weighing in as a notebook-style unit with a 128G SSD, it ensures fast boot times for emergency “Point of Care” (POCUS) use.
-
| Category | Technical Specification | Veterinary Benefit |
| Monitor Size |
≥15-inch
|
Clear visualization of tiny anatomical structures. |
| Dynamic Range |
20-280dB
|
Superior gray-scale contrast for soft tissue differentiation. |
| Cine Loop |
≥600 frames
|
Allows for frame-by-frame review of rapid heartbeats. |
| Body Marks |
≥80 types
|
Includes specific anatomical markers for accurate documentation. |
| Connectivity |
6 USB, 1 HDMI, 1 RJ-45
|
Seamless DICOM 3.0 export to PACS or telemedicine platforms.
|
| Reliability |
≥2-year warranty
|
Long-term security for small clinic investments. |
Post time: Dec-30-2025
